PAJ7620 Gesture Recognition Sensor PAJ7620U2, 9 Gesture Recognition For Arduino
Review: 5 - "A masterpiece of literature" by John Doe, written onMay 4, 20020
Great

PAJ7620 Gesture Recognition Sensor PAJ7620U2, 9 Gesture Recognition For Arduino

Available:In Stock
  • Product SKU: KG1026
Wishlist
₹ 549 ₹ 879
Available offers
Best Rates

on Express Shipping – Hurry! Shipping starts from Rs69.

Tc
Free Shipping Offer -

Avail free shipping on all orders above Rs999.

Tc
Volume Discounts-

Buy More Save More! Discounts upto 20%. Contact us

Special Bulk Discounts

for colleges, Schools, Companies & resellers Contact us

Cash on Delivery

Available above Rs 999

Tc
Highlights
  • Original, High Quality
  • KitsGuru Warranty
Services
  • Email Support
  • Video Support to be purchased separately
Easy Payment Options
  • Netbanking
  • Debit/Credit cards
  • Cash on Delivery
  • E-wallets/UPI
Shipping Details
International Shipping
Available

  Need Volume Discounts? Deals are specially designed for you. Click here

  Need Customization? Provide us more details Click here

Warehouse Details   27H-168

  • Order within
Secure

Specification

Description

PAJ7620U2 can recognize 9 commonly used hand gestures for controlling Arduino projects including move up, move down, move left, move right, move forward, move backward, circle-counter clockwise, circle-clockwise, and wave. These gesture data can be directly accessed via the I2C bus interface. The PAJ7620 also gives built-in ability of proximity detection for the purpose of sensing objects approaching or departing. The PAJ7620 is designed with great flexibility in its power-saving mechanism.

Here are some key points about the PAJ7620 gesture recognition sensor:

Gesture Recognition: The PAJ7620 sensor is capable of recognizing a variety of hand gestures. It can detect and interpret gestures such as moving your hand left or right, up or down, and more complex gestures like a wave or circle.

Arduino Compatibility: The sensor can be easily interfaced with Arduino boards. It communicates with the Arduino via I2C (Inter-Integrated Circuit) communication, making it simple to integrate into your Arduino projects.

Library Support: To use the PAJ7620 with Arduino, you'll typically need to install a library that provides functions for interacting with the sensor. There are Arduino libraries available for the PAJ7620 sensor that simplify the process of reading gesture data.

Gesture Output: The sensor provides gesture data in a digital format, making it straightforward to process and incorporate into your Arduino code. You can use this data to trigger actions or control devices based on specific gestures.

Power Supply: The sensor requires a power supply voltage within its specified operating range. Be sure to provide the correct voltage to the sensor to ensure it functions correctly.

Applications:

The PAJ7620 sensor can be used in various applications, including gesture-controlled robotics, gaming interfaces, smart home automation, and interactive displays.

Features

  • Built-in proximity detection,
  • Flexible power saving scheme,
  • Ambient light noise cancellation,
  • Nine gesture recognition (Up / Down / Left / Right / Push / Pull / CW / CCW / Wave),
  • Gesture speed is 60°/s to 600°/s in Normal Mode and 60°/s to 1200°/s in Gaming Mode,
  • Ambient light immunity: < 100k Lux.
  • I2C Interface up 400 Kb/Sec

Technical Details

  • Operating voltage: 3.3V/5V
  • Communication interface: I2C
  • Recognition distance: 5cm ~ 15cm
  • Recognition rate: 240Hz
  • Recognition angle: 60° (diagonal)
  • Mounting hole size: 3.0mm
  • Current Consumption operation State: 2.82 mA
  • Current Consumption standby State: 2.3mA

Applications

  • Automobile Application
  • Home Automation
  • Gesture-Controlled Lock
  • Hand Gesture Controlled Robot
  • Gesture Mouse

Pin Out

  • VCC:3.3V / 5V
  • GND: Ground
  • SCL: I2C Clock Port
  • SDA:I2C Data Port
  • INT:Interrupt Output

Physical Attributes

  • L x W x H (mm): 20.2 x 16 x 5
  • Weight (g): 8

Product Video

Documentation

Package Includes

  • 1 x PAJ7620U2 Breakout Board
  • 1 x 6-way straight header pin
