The module is based on the LM393 comparator IC and features an electric condenser microphone for high sensitivity sound detection. It provides both analog output and digital (threshold-based) output, allowing flexible integration depending on project requirements. A built-in power indicator LED and comparator output indicator make debugging and testing easy.
-24%
Small Microphone Sound Sensor Module
Available:Out of Stock
- Product SKU: KG1310
₹ 52
₹ 69
Specification
Description
High Sensitivity Sound Sensor Microphone Module (LM393)
This Sound Sensor Microphone Module is designed for detecting sound intensity and converting it into usable electrical signals for microcontroller-based projects. It is especially suitable for applications such as interactive voice switches, sound-controlled lights, and loudness level indicators.The module is based on the LM393 comparator IC and features an electric condenser microphone for high sensitivity sound detection. It provides both analog output and digital (threshold-based) output, allowing flexible integration depending on project requirements. A built-in power indicator LED and comparator output indicator make debugging and testing easy.
Features
- High sensitivity sound detection using condenser microphone
- Powered by 5V DC supply
- Provides analog output for sound intensity measurement
- Digital comparator output with adjustable threshold
- Threshold level output flip supported
- Low-level output signal suitable for sound-controlled lighting
- Power indicator LED for status indication
- Comparator output LED for easy visual feedback
- 3 mm mounting hole for easy installation
Technical Details
- Item Type: Sound Sensor Module
- Operating Voltage: 5 V DC
- IC Chip: LM393 Comparator
- Microphone Type: Electric condenser microphone
- Output Types: Analog & Digital (Comparator)
- PCB Size (L × W): 35 × 14 mm
- Mounting Hole Diameter: 3 mm
Applications
- Sound-activated switches
- Sound-controlled lighting systems
- Loudness and noise level detection
- Interactive voice-based projects
- Arduino and microcontroller learning projects
Physical Attributes
- Compact PCB design
- Dimensions: 35 × 14 mm
- Integrated mounting hole (3 mm)
- Weight:4g
Package Includes
- 1 × Analog Sound Sensor Microphone Module for Arduino
