12V 450mA 5W AC-DC Power Supply Buck Converter Step Down Module

12V 450mA 5W AC-DC Power Supply Buck Converter Step Down Module

Available:In Stock

Product SKU: KG334

Wishlist

₹ 171 ~~₹ 199~~

Available offers

Best Rates

on Express Shipping – Hurry! Shipping starts from Rs69.

Free Shipping Offer -

Avail free shipping on all orders above Rs999.

Volume Discounts-

Buy More Save More! Discounts upto 20%. Contact us

Special Bulk Discounts

for colleges, Schools, Companies & resellers Contact us

Cash on Delivery

Available above Rs 499

Highlights

Original, High Quality
KitsGuru Warranty

Services

Email Support
Video Support to be purchased separately

Easy Payment Options

Netbanking
Debit/Credit cards
Cash on Delivery
E-wallets/UPI

Shipping Details

International Shipping

Available

Quantity

Need Volume Discounts? Deals are specially designed for you. Click here

Need Customization? Provide us more details Click here

Warehouse Details 13D-122

Specification

Description

Step Down Module with temperature protection, over current protection and short circuit protection, high and low voltage isolation, AC85 ~ 265 v wide voltage input, ac/dc current, 431 precision voltage stability DC12V output

Technical Details

Input voltage: AC 85 ~ 265 v 50/60 hz or DC 100~ 370 v
Input current: 0.0273A(AC110V) 0.014A(AC220V)
Input Inrush Current: 20A
Output voltage: DC 12V (+ / – 0.2 V)
Output current 500 mA
Operating temperature -20~60Deg.C
Relative humidity 40-90%RH
Output 12V, min current 0a, max current 500mA, peak current: 600mA, output range:11.80~12.1V, ripple wave: 150mV
Output power:0-6W(DC current)
Output efficiency: 80%
Switch machine overshoot: MAX 10%
Output voltage rise time: MAX 100MS
Output over voltage: 11.8-12.1V, recovery: Lock, restart after recovery
Output overpower protection: YES, recovery: Lock, restart after recovery
Short-circuit protection: YES, automatic recovery after problem solved
Temperature protection: YES, recovery: Lock, restart after recovery
Overcurrent protection: YES, recovery: Lock, restart after recovery
