Three phase 110/86 Stepper Motor Digital Driver 3DM2283 Current 8A 220V

Three phase 110/86 Stepper Motor Digital Driver 3DM2283 Current 8A 220V

Available:In Stock

Product SKU: LGSTM063

Wishlist

₹ 12,999 ~~₹ 15,999~~

Available offers

Best Rates

on Express Shipping – Hurry! Shipping starts from Rs69.

Free Shipping Offer -

Avail free shipping on all orders above Rs999.

Volume Discounts-

Buy More Save More! Discounts upto 20%. Contact us

Special Bulk Discounts

for colleges, Schools, Companies & resellers Contact us

Cash on Delivery

Available above Rs 499

Highlights

Original, High Quality
KitsGuru Warranty
Digital Microstep Control
Up to 8.0A Output
Ultra-Fine Microstepping
Low Noise Operation
Opto-Isolated Inputs
Industrial Metal Body

Services

Email Support
Video Support to be purchased separately

Easy Payment Options

Netbanking
Debit/Credit cards
Cash on Delivery
E-wallets/UPI

How Fast We Ship

International Shipping

Available

Quantity

Need Volume Discounts? Deals are specially designed for you. Click here

Need Customization? Provide us more details Click here

🏠 Warehouse Details:

22 D - 118

Specification

Description

3DM2283 Digital Microstep Driver

3DM2283 Digital Microstep Driver is a high-performance digital stepper motor driver designed for accurate and stable control of 2-phase bipolar stepper motors. Using advanced digital control technology, it delivers smooth motion, reduced vibration, and consistent torque output, even at high speeds.

This driver supports wide current adjustment and multiple microstepping resolutions via DIP switches, making it suitable for CNC machines, automation equipment, and industrial motion-control systems. Its rugged metal enclosure ensures reliable operation in demanding environments.

Features

Advanced digital microstepping control
Compatible with 2-phase bipolar stepper motors
Wide adjustable output current range
Multiple microstep resolutions via DIP switches
Smooth motion with low noise and low vibration
Opto-isolated STEP / DIR / ENA inputs
Built-in protection for safe and stable operation
Industrial-grade metal enclosure

Applications

CNC routers and CNC milling machines
Laser cutting and engraving machines
Industrial automation systems
Robotics and positioning platforms
Packaging, printing, and textile machinery

Technical Details

Model: 3DM2283
Driver Type: Digital Microstep Stepper Driver
Motor Type: 2-Phase Bipolar Stepper Motor
Output Current Range (Peak): 3.2A – 8.0A (selectable)
Output Current Setting: DIP switch selectable
Microstep Resolutions: 400 / 500 / 600 / 800 / 1000 / 1200 / 2000 / 3000 / 4000 / 5000 / 6000 / 10000 / 12000 / 20000 / 30000 / 60000 pulses per revolution
Control Signals: PUL (STEP), DIR (Direction), ENA (Enable)
Control Signal Voltage: 5–24V
Input Type: Opto-isolated
Microstep Mode Selection: External / Internal (SW10)
Operating Mode: Digital constant current drive
Protection Features: Over-current, Over-voltage, Under-voltage, Motor phase error, Over-temperature
Status Indication: LED fault indication
