Infrared IR PIR Sensor Switch Module Body Save Energy Motion Auto ON Off Light
Available:In Stock
- Product SKU: KG498
₹ 419
₹ 499
Need Volume Discounts? Deals are specially designed for you. Click here
Need Customization? Provide us more details Click here
🏠
Warehouse Details:
Specification
Description
Passive Infrared Sensor Switch Module Body Save Energy Motion Auto ON Off Light
This IR motion sensor light switch uses a high-precision passive infrared sensor and advanced circuitry, so when someone enters its detection range the light turns on automatically. It is useful for smart environments like pir sensor to arduino projects and lighting automation. This passive infrared sensor use makes the system more energy-efficient with automatic delay-off functionality.Technical Details
- Type: IR Motion Sensor Light Switch
- Working Power: AC100V - 250V, 50/60HZ
- Load Power: LED ≤ 40W, Energy Saving ≤ 60W, Incandescent ≤ 100W, Fan ≤ 50W
- Standby Power: 0.0088W
- Illumination: 5 LUX – 5000 LUX
- Sensor Distance: 6m – 10m
- Sensor Angle: 110° – 140°
Features
- Super saving electricity – power consumption ~0.08 units per year
- Wide voltage range (100V–250V) ensuring stable performance
- Load capacity: LEDs ≤ 60W, filament lamps ≤ 100W
- Non-contact installation — connects same as ordinary switch
- Lightning protection with strong anti-interference
- Suitable for corridors, toilets, basements, warehouses, garages, etc.
- Supports automation including pir sensor to arduino custom projects
Applications :
- Home Automation: A passive infrared sensor use to turn on lights with motion.
- Security Systems: Activates lighting upon detecting movement.
- Energy Conservation: Conserves power with automatic switch-off when no motion is detected.
- Automated Lighting: Ideal for staircases, parking lots, and corridors.
- Smart Homes: Easy to integrate as a passive infrared sensor based trigger.
- Robotics: pir sensor to arduino helps robots detect and respond to motion.
- Industrial Automation: Activates lighting when workers are present.
- Medical Applications: Automatically illuminates patient areas.
Attention
- Turn off power before installation and ensure it is installed by a professional.
- Requires ~45 seconds warm-up time after powering ON.
- Do not overload the switch.
Physical Attributes
- Dimensions (L × W): 86 × 86 mm
- Weight: 58 g
Package Includes
- 1 x Infrared IR PIR Sensor Switch Module Body Save Energy Motion Auto ON Off Light
