Ultrasonic Distance Sensor Module

Name: Ultrasonic Distance Sensor Module
Availability: InStock
Rating: 4.88 (25 reviews)

Available:In Stock

Product SKU: KG042

Wishlist

₹ 55 ~~₹ 69~~

Available offers

Best Rates

on Express Shipping – Hurry! Shipping starts from Rs69.

Free Shipping Offer -

Avail free shipping on all orders above Rs999.

Volume Discounts-

Buy More Save More! Discounts upto 20%. Contact us

Special Bulk Discounts

for colleges, Schools, Companies & resellers Contact us

Cash on Delivery

Available above Rs 499

Highlights

Original, High Quality
KitsGuru Warranty
Model: RCWL-1604
Voltage: 5V
Frequency: 40kHz
Range: 2cm–4m
Resolution: 0.3cm
Pins: GND, Echo, Trig, VCC

Services

Email Support
Video Support to be purchased separately

Easy Payment Options

Netbanking
Debit/Credit cards
Cash on Delivery
E-wallets/UPI

Shipping Details

International Shipping

Available

Quantity

Need Volume Discounts? Deals are specially designed for you. Click here

Need Customization? Provide us more details Click here

Warehouse Details 11B-109

Specification

Description

Ultrasonic Distance Sensor Module

The RCWL-1604 Ultrasonic Sensor is a versatile and widely used component in the field of electronics and robotics. This sensor utilizes ultrasonic waves to measure the distance to an object, making it ideal for distance measurement, object detection, and obstacle avoidance. Its ease of use and reliability make it a popular choice for hobbyists, educators, and professionals.

Technical Details

Model: RCWL-1604
Operating Voltage (VDC): 5
Frequency: 40 kHz
Measurement Range: 2 cm to 4 m
Resolution: 0.3 cm
Connection Type: 4-pin (GND, Echo, Trig, VCC)

Features

High accuracy
Wide detection range
Compact and lightweight
Low power consumption
Simple interface
Real-time feedback

Pin Description:

GND: Ground connection
ECHO: Echo pin for receiving measurement signal
TRIG: Trigger pin for initiating measurement
VCC: Power input (+5V or +3.3V)

Applications :

Distance Measurement: Accurately measures the distance between the sensor and an object, which is useful in various automation and control systems.
Obstacle Avoidance: Used in robotics to detect and avoid obstacles, ensuring smooth navigation.
Object Detection: Ideal for security systems, automated doors, and other systems requiring object presence detection.
Level Measurement: Measures liquid or material levels in containers, useful in industrial and agricultural settings.
