48V 1500W 31.3A AC to DC Industrial Grade Switching Power Supply SMPS IP20 Aluminum Case
![48V 1500W 31.3A AC to DC Constant Voltage SMPS Power Supply]()
![48V DC Fan Cooling SMPS for LED CNC CCTV Applications]()
![48V 1500W IP20 Switching Power Supply with 110V-220V Input]()
![48V 1500W 31.3A AC to DC Constant Voltage SMPS Power Supply]()
![48V DC Fan Cooling SMPS for LED CNC CCTV Applications]()
![48V 1500W IP20 Switching Power Supply with 110V-220V Input]()
Built for reliable continuous operation, this SMPS supports air cooling and fan cooling for effective heat dissipation during use. It offers a conversion efficiency of ≥80%, works within a temperature range of -30°C to +50°C, and comes with IP20 protection for indoor electrical installations. Its compact size of 253 × 125 × 65mm makes it suitable for control panels, automation systems, machinery wiring, and industrial power supply applications.
-27%
48V 1500W 31.3A AC to DC Industrial Grade Switching Power Supply SMPS IP20 Aluminum Case
Available:In Stock
- Product SKU: KG1382
₹ 12,999
₹ 17,999
Need Volume Discounts? Deals are specially designed for you. Click here
Need Customization? Provide us more details Click here
🏠
Warehouse Details:
Specification
Description
48V 1500W 31.3A AC to DC Constant Voltage Switching Power Supply SMPS – 110V-220V Input, IP20
The 48V 1500W 31.3A AC to DC Constant Voltage Switching Power Supply SMPS is designed to convert AC110/220V 50/60Hz input into a stable DC48V output for high-power electrical and electronic applications. With a rated load of 1500W Max and output current up to 31.3A Max, this power supply is suitable for LED lighting systems, CNC machines, CCTV setups, DC motors, machinery, and other compatible 48V DC equipment.Built for reliable continuous operation, this SMPS supports air cooling and fan cooling for effective heat dissipation during use. It offers a conversion efficiency of ≥80%, works within a temperature range of -30°C to +50°C, and comes with IP20 protection for indoor electrical installations. Its compact size of 253 × 125 × 65mm makes it suitable for control panels, automation systems, machinery wiring, and industrial power supply applications.
Technical Details
- Product Type: AC to DC Constant Voltage Switching Power Supply SMPS
- Rated Load: 1500W Max
- Output Voltage: DC48V
- Output Current: 31.3A Max
- Input Voltage: AC110/220V 50/60Hz
- Conversion Efficiency: ≥80%
- Power Factor: N
- Working Temperature: -30°C to +50°C
- Temperature Rise: ≤30°C
- Storage Temperature: -30°C to +100°C
- IP Code: IP20
- Cooling Type: Air Cooling, Fan Cooling
- Application: LED strip light, LED down light, LED panel light, CNC, CCTV, Motor, Machinery etc.
Features
- Stable DC48V output
- Constant voltage design
- 1500W maximum load
- 31.3A output current
- AC110/220V input
- ≥80% conversion efficiency
- Air and fan cooling
- IP20 protection rating
- Suitable for continuous use
- Compact installation size
Applications
- LED strip lighting systems
- LED downlights
- LED panel lights
- CNC machines
- CCTV surveillance systems
- DC motors
- Industrial machinery
- Automation control equipment
- 48V DC compatible devices
Physical Attributes
- Dimension: 253 × 125 × 65 mm
- Cooling Type: Air Cooling, Fan Cooling
- IP Code: IP20
- Weight:1442g
- Storage Temperature: -30°C to +100°C
Package Includes
- 1 x 48V 1500W 31.3A AC to DC Constant Voltage Switching Power Supply SMPS
