650nm 6mm base 5V DC 5mW Red Laser Dot Diode Industrial Grade Module
- Product SKU: KG094
Specification
Description
650nm 6mm base 5V DC 5mW Red Laser Dot Diode
650nm 6mm 5V DC 5mW Mini Laser Dot Diode Module which is made of copper plastic. It is suitable for 3V 5mW standard, with 6mm outside diameter,and can be used to connect diode tubes for multiple uses.Technical Details: 650nm 6mm base 5V DC 5mW Red Laser Dot Diode Industrial Grade Module
- Item Type: Laser Module
- Voltage Rating (V): 5
- Weight (g): 1.3
- Operating Temperature (°C): -10 to 50
- Rated Power (mW): 5mW
- Wavelength (nm): 650
- Working Current (mA): <40mA
- Working Lifespan (h): more than 2000 hours
- Cable Length (cm): 7
Features
- Wavelength: 650nm red laser for bright beam.
- Compact: 6mm base, easy integration.
- Low Power: 5V DC, 5mW output.
- Long Lifespan: Over 2000 hours.
- High Precision: Accurate laser point.
- Wide Temperature: Operates from -10°C to 50°C.
- Industrial Grade: Reliable for industrial use.
- Low Current: <40mA for efficient operation.
Applications :
- Laser Pointers: Used in handheld devices for pointing and presentations.
- Alignment and Positioning Systems: Provides a visible laser beam for precise alignment in industrial and scientific applications.
- Laser-Based Measurement Tools: Utilized in laser distance meters or level measurement devices for accurate readings.
- Optical Communication Systems: Can be used for short-range optical communication due to its visible red light.
- Barcode Scanners: Serves as a laser light source in barcode scanning applications, helping with fast and accurate reading.
Physical Attributes: 650nm 6mm base 5V DC 5mW Red Laser Dot Diode Industrial Grade Module
- Dimensions(Dia. x Len.) mm : 6 × 10
- Cable Length (mm): 7
- Weight (gm): 1.3
Package Includes
- 1 x 650nm 6mm base 5V DC 5mW Red Laser Dot Diode Industrial Grade Module
Customer Reviews
Used this for my steampunk gun! love it!
Out of the bag all 10 work. All I did was hook them up in series with a 330 resistor from a 5v source and there it is. Hope they last :)
I'm using this product on several projects including alignment tools and sensing projects.
I tested all of the ones I received, they all worked. They all have a bright beam that does spread the further you aim, but keep a good brightness. I even pushed one by using 12 volts for about 5 seconds, didn't burn out, but got very hot. I'm happy with my purchase, now to find projects to use them
Nice laser components and cheap. Obviously, they are not light sabers and might need additional optics depending on the applications.
good for DIY works. good beam profile. Also can be salvaged for the collimatng lens of 3mm focal length.
Working on a lighting project with a raspberry pi.
Depending on the target distance the dot may be out of focus, but twisting the two halves of the case lets you focus a tiny dot even at distance or close up. Run from a 18650 LiIon cell uses about 17.5 mA and lasts almost a week!
Great affordable laser modules
I haven't done anything but tested one, and it looks great and operational of descently small laser.
