6V 200RPM DC 6V GA12 N20 Micro Metal Gear Box Vertical Shaft

6V 200RPM DC 6V GA12 N20 Micro Metal Gear Box Vertical Shaft_1

6V 200RPM DC 6V GA12 N20 Micro Metal Gear Box Vertical Shaft_2

6V 200RPM DC 6V GA12 N20 Micro Metal Gear Box Vertical Shaft

Name: 6V 200RPM DC 6V GA12 N20 Micro Metal Gear Box Vertical Shaft
Availability: OutOfStock
Rating: 5.0 (4 reviews)

Available:Out of Stock

Product SKU: KG173

Wishlist

₹ 499 ~~₹ 599~~

Pre-order

Specification

Description

DC geared motor is compact mechanical structure, lightweight and small size, strong usability, high safety, and reliability. The direction of the output shaft of the gearbox is perpendicular to the motor shaft, and the output shaft direction of the entire motor body is ultra‑short compared with ordinary geared motors.

6V 200 turn miniature gear motor is made of metal gear, is wear-resistant prevents tooth breakage, so it has a long service life. This electronic gear motor is a good replacement for old or worn electronic deceleration motor, useful and practical. This gear motor is suitable for elevators, landing gear, mechanical arms, electronic toys, and many other devices.

Features:

The direction of the gearbox's output shaft is perpendicular to the motor shaft, and the output shaft direction of the entire motor body is ultra‑short compared with ordinary geared motors.

The worm gear motor is self‑locking, that is, when the motor is without electricity, the output shaft cannot rotate, that is, self‑locking.

Compact mechanical structure, lightweight and small size, strong usability, high safety, and reliability.

The DC-geared motor is with a worm; change the rotation of the motor by changing the wiring method.

Compatible: Geared Motors Are Widely Used in Window Openers, Door Openers, Miniature Winches, etc.

Application:

Robotics: It’s perfect for small robots requiring controlled movements, especially on wheels, arms, or other moving parts.

DIY Electronics Projects: Popular among hobbyists for building automated systems like small conveyor belts, motorized toys, or Arduino-based projects.

Outline Drawing

Technical Details

Item Type: Motor
Model: GA12-N20
Rated Voltage: DC 6V
No-Load Speed: 400RPM
Revolving speed: 200 RPM
Torque: 0.2kg.cm
Material: Metal
Direction: CW/ CCW

Physical Attributes

Length * Width * Height (mm) : 24 * 20 * 5 mm
Weight (gm) : 14

Documentation

Datasheet

Package Includes

1 x 6V 200RPM DC 6V GA12 N20 Micro Metal Gear Box Vertical Shaft

Works as descibed

Works as descibed

Strong!

Good product

stronger than they look for their size.

I am sure i will eventually find another project for this/

Exceeded my expectations.

I was pleased to verify that when I gave it half the rated voltage (3V from two AAA batteries), it operated reliably at half the stated speed. When I gave it a quarter of the rated voltage (1.5 volts from one AAA battery), it operated reliably at a quarter of the rated speed. It still had very good torque at the lower voltages and speeds.
