74HC164D Serial-In Parallel-Out Shift Register IC – High-Speed CMOS Logic, 16-Pin SMD
The 74HC164D is an 8-bit serial-in/parallel-out Shift Register that features two serial data inputs (DSA and DSB), and eight parallel data outputs (Q0 to Q7). Data is entered serially through DSA or DSB, and either input can be used as an active high enable for data entry through the other input. Data is shifted on the low-to-high transitions of the clock (CP) input. A low on the master reset input (MR) clears the register and forces all outputs low, independently of other inputs. Inputs include clamp diodes. This enables the use of current-limiting resistors to interface inputs to voltages in excess of VCC.Technical Details
- IC Type: Shift Register
- Shift Register Function: Serial to Parallel
- No. of Elements: 1 Element
- Logic Family / Base Number: 74HC164
- Logic IC Family: 74HC
- Logic IC Base Number: 74164
- IC Output Type: Standard
- No. of Pins: 14
- Case/Package: SOIC
- Minimum Supply Voltage: 2V
- Maximum Supply Voltage: 6V
- Operating Temperature Range: -40°C to +125°C
Features
- CMOS input logic levels
- Gated serial data inputs
- Asynchronous master reset
- Complies with JEDEC standard No. 7A
Applications
LED and Display Control – Used to expand I/O for driving multiple LEDs or 7-segment displays using few microcontroller pinsData Bus Expansion – Converts serial data into parallel output, ideal for expanding digital outputs in embedded systems
Microcontroller Interfacing – Helps interface low-pin-count microcontrollers with parallel-output devices.
Physical Attributes
- Dimensions: ~4.6mm x 3.7mm x 1.8 mm (L x W x H)
- Weight: ~0.05g
Package Includes
- 1 x MB10S Bridge Rectifier – 1.5A 1000V, Large Chip, High Quality SMD
