BMP390 Precision Atmospheric Pressure Altimeter Sensor Pressure Module
Available:Out of Stock
- Product SKU: KG879
₹ 869
₹ 1,099
Specification
Description
BMP390 Precision Atmospheric Pressure Altimeter Sensor Pressure Module
The Waveshare BMP390 High Precision Barometric Pressure Sensor is an advanced sensor module designed to accurately measure barometric pressure, altitude, and temperature. It is a compact and versatile device that offers high precision and reliability in a wide range of applications. The sensor utilizes Bosch’s state-of-the-art BMP390 chip, which incorporates advanced sensing technologies and algorithms. This allows for precise measurements with a resolution as low as 0.01 hPa (hectopascal) for pressure, 0.1 meters for altitude, and 0.01 degrees Celsius for temperature.Technical Details
- Model Type: Barometric Pressure Sensor
- Model No.: BMP390
- Communication: I2C / SPI
- Pressure Range: 300~1250 hPa
- Absolute Accuracy: ±0.50 hPa (300-1100 hPa, 0~65℃)
- Relative Accuracy: ±0.03 hPa (700-1100 hPa, 25~40℃)
- Temperature Coefficient: ±0.6 Pa/K (900 hPa, 25-40°C)
- Max Sampling Rate: 200Hz
- Operating Temperature: -40~85℃
Features
- Onboard BMP390 sensor for barometric pressure, altitude, and temperature
- Supports I2C communication with configurable address & cascading
- Supports SPI communication via CS pin (default: I2C)
- Onboard voltage translator for 3.3V/5V compatibility
- Includes online resources & examples for Raspberry Pi, Pico, Arduino, ESP32
Applications :
- Weather Monitoring: Measures atmospheric pressure for forecasting
- Altitude Measurement: Used in drones, aviation, and GPS systems
- Environmental Sensing: Ideal for IoT and smart home applications
- Industrial Applications: Pressure monitoring in automation and HVAC systems
- Wearable Devices: Integrated into fitness trackers for altitude tracking
Physical Attributes
- Dimensions(mm): 50.6 x 45.7x 19.5
- Weight: 3 g
Package Includes
- 1 XBMP390 Precision Atmospheric Pressure Altimeter Sensor Pressure Module
