The ISD1820 Recording Module with On-Board Mic and Loud Speaker is a module used for recording and playing back audio messages.

Here's an overview of the ISD1820 Recording Module:

Purpose: The ISD1820 module is designed for recording and playing back audio messages. It includes an onboard microphone and loudspeaker for convenient audio recording and playback.

Functionality: It allows users to record their voice or other sounds, store the recordings in non-volatile memory, and play them back through the built-in speaker.

Audio Interface: The module provides a simple way to interact with audio content without needing complex audio processing.


Audio Recording: The module allows users to record audio messages using the onboard microphone.

Non-Volatile Storage: Recordings are stored in non-volatile memory, ensuring they are retained even when power is turned off.

Audio Playback: The recorded audio messages can be played back through the module's onboard loudspeaker.

Control Interface: It typically features control buttons or pins for recording, playback, and other functions.

Voltage Regulation: Some versions of the module might include voltage regulation for stable operation.


Voice Recording: Used for recording and playing back voice messages, reminders, or announcements.

Audio Effects: Employed in projects that require adding simple sound effects or voice prompts.

Interactive Projects: Suitable for interactive projects where audio feedback enhances user experience.

Educational Demonstrations: Used to demonstrate audio recording and playback principles in educational settings.

Using the ISD1820 Recording Module:

Wiring: Connect the module's pins to the appropriate pins on your microcontroller or other control devices.

Powering the Module: Provide the module with the required power supply (usually 3.3V or 5V) and ground connection.

Recording: Press the designated button to initiate recording. The microphone captures the audio input.

Playback: Press the playback button to play back the recorded audio through the onboard loudspeaker.


Audio Quality: The audio quality might vary based on the module's components and settings.

Storage Duration: The length of the recording is often limited by the available memory on the module.

Technical Details: ISD1820 Voice Recording Module

  • The main chip: ISD1820
  • Operating Voltage (V): DC 3 ~ 5
  • Loudspeaker: 8 Ω, 0.5W


Physical Attributes: ISD1820 Voice Recording Module

  • Speaker Connecting Cable Length (cm): 20
  • Speaker Diameter (mm): 40
  • Length * Width * Height (in mm) : 42 * 38 * 14
  • Weight (gm): 22


Integration with Arduino

ISD1820 Voice Recording Module


Sample Code


Additional Details: ISD1820 Voice Recording Module

  • An easy to use 10 seconds of voice recording.
  • High-quality, natural voice restored.
  • Can be used as a propaganda module.
  • With looping, jog playback, and single-pass play function.
  • Available single-chip control.
  • This module can directly drive a small speaker 8 ohms 0.5W.
  • Audio recording control mode: the key to control or microcontroller, IO has drawn the line of control.


Product Video


Package Includes

  • 1 x ISD1820 Recording Module Voice Board With On Board Mic and Loud Speaker
