CJ78L10 Voltage Regulator IC – 10V 3-Terminal LDO Regulator

The CJ78L10 is a compact 3-terminal low dropout (LDO) linear voltage regulator IC designed to provide a stable 10V output for low-current electronic applications. Capable of delivering up to 100mA of current, it is ideal for powering logic circuits, analog components, and embedded systems.

It includes built-in thermal shutdown and overcurrent protection for safe and reliable operation. Available in both TO-92 and SOT-89 packages, it supports both through-hole and surface-mount designs.

Note: For best performance, use a 0.33µF input capacitor and a 0.1µF output capacitor.

Technical Details

  • IC Name: CJ78L10
  • Type: Fixed 10V Low Dropout Voltage Regulator
  • Output Voltage: 10V ±5%
  • Output Current: Up to 100mA
  • Input Voltage Range: 12V to 25V
  • Dropout Voltage: ~1.7V typical
  • Quiescent Current: ~5mA
  • Line Regulation: Max 180mV
  • Load Regulation: Max 90mV
  • Internal Thermal Shutdown
  • Short Circuit and Overcurrent Protection
  • Package: TO-92 / SOT-89
  • Mounting Type: Through-hole / SMT
  • Operating Temperature: -40°C to +125°C

Features

  • Fixed 10V regulated output
  • Provides up to 100mA output current
  • Low dropout and power consumption
  • Integrated thermal and short-circuit protection
  • Available in TO-92 and SOT-89 packages
  • Simple 3-pin configuration
  • Ideal for analog, digital, and embedded circuits

Applications

  • Logic and analog circuit power supply
  • Microcontroller and sensor modules
  • Battery-powered embedded devices
  • Low-current analog electronics
  • DIY and educational electronic projects

Physical Attributes

  • Available Packages: TO-92 (Bulk) / SOT-89 (SMT)
  • Pin Count: 3
  • TO-92 Dimensions: ~4.5mm x 4.0mm x 5.0mm (W x D x H)
  • SOT-89 Dimensions: ~4.5mm x 2.5mm x 1.6mm
  • Mounting Type: TO-92 – Through-hole, SOT-89 – Surface Mount
  • Weight: ~0.2g (TO-92), ~0.1g (SOT-89)

Package Includes

  • 1 x CJ78L10 Voltage Regulator IC (TO-92 or SOT-89, as selected)
