CJ78L12 Voltage Regulator IC – 12V 3-Terminal LDO Regulator

The CJ78L12 is a compact 3-terminal low dropout (LDO) linear voltage regulator IC designed to deliver a consistent 12V output for low-current electronic circuits. It supports up to 100mA output current, making it ideal for use in logic circuits, analog modules, and embedded control systems.

With built-in thermal shutdown and overcurrent protection, it ensures safe and stable operation under varying load conditions. Available in TO-92 and SOT-89 packages, it is suitable for both through-hole and surface-mount assembly.

Note: For improved stability, use a 0.33µF input capacitor and a 0.1µF output capacitor.

Technical Details

  • IC Name: CJ78L12
  • Type: Fixed 12V Low Dropout Voltage Regulator
  • Output Voltage: 12V ±5%
  • Output Current: Up to 100mA
  • Input Voltage Range: 14V to 30V
  • Dropout Voltage: ~1.7V typical
  • Quiescent Current: ~5mA
  • Line Regulation: Max 200mV
  • Load Regulation: Max 100mV
  • Internal Thermal Shutdown
  • Short Circuit and Overcurrent Protection
  • Package: TO-92 / SOT-89
  • Mounting Type: Through-hole / SMT
  • Operating Temperature: -40°C to +125°C

Features

  • Fixed 12V regulated output
  • Delivers up to 100mA output current
  • Low power consumption and dropout voltage
  • Built-in thermal and overcurrent protection
  • Available in TO-92 and SOT-89 packages
  • Simple 3-pin connection for easy integration
  • Ideal for low-current analog and digital circuits

Package Includes

  • 1 x CJ78L12 Voltage Regulator IC 12V 3-Terminal LDO Regulator
