DB105S 1A 1000V Single-Phase Bridge Rectifier Diode – SMD Package

The DB105S is a compact, high-efficiency single-phase full-wave bridge rectifier designed for AC to DC conversion in surface-mount applications. With a maximum reverse voltage of 1000V and capable of handling up to 1A of average forward current, this rectifier is ideal for low-power power supplies, LED drivers, chargers, and embedded systems.

Housed in a space-saving SMD (Surface-Mount Device) package, the DB105S supports automated assembly and is well-suited for high-density circuit designs.

Technical Details

  • Part Number: DB105S
  • Type: Single-Phase Bridge Rectifier
  • Average Forward Current (IF(AV)): 1A
  • Peak Repetitive Reverse Voltage (VRRM): 1000V
  • Maximum RMS Voltage: 700V
  • Maximum Forward Voltage Drop (VF): ~1.0V per diode
  • Peak Forward Surge Current (IFSM): 30A
  • Reverse Recovery Time: Fast
  • Operating Temperature Range: -55°C to +150°C
  • Package: SMD (typically MBLS / DB-MBLS form)
  • Mounting Type: Surface Mount

Features

  • Full-wave bridge rectifier in a single compact package
  • High reverse voltage capability: up to 1000V
  • Low forward voltage drop for energy efficiency
  • High surge current handling: up to 30A
  • Reliable and thermally stable design
  • Space-saving SMD form factor for dense PCBs

Applications

  • AC to DC power supply circuits
  • LED lighting and driver modules
  • Battery charging circuits
  • Consumer electronics and embedded systems
  • Surface-mount rectifier modules

Physical Attributes

  • Package Type: SMD (MBLS / DB-MBLS)
  • Pin Configuration: 4-pin bridge layout
  • Dimensions: ~5.0mm x 4.2mm x 1.7mm (L x W x H)
  • Mounting Type: Surface Mount
  • Weight: ~0.3g

Package Includes

  • 1 x DB105S 1A 1000V Bridge Rectifier Diode – SMD Package
