Ebike MY1016Z3 24V 350W Gear DC Motor – 324 RPM
Review: 5 - "A masterpiece of literature" by , written on May 4, 20020
Great

Ebike MY1016Z3 24V 350W Gear DC Motor – 324 RPM

Available:In Stock
  • Product SKU: KG101
Wishlist
₹ 3,999 ₹ 5,999
Available offers
Best Rates

on Express Shipping – Hurry! Shipping starts from Rs59.

Tc
Free Shipping Offer -

Avail free shipping on all orders above Rs999.

Tc
Volume Discounts-

Buy More Save More! Discounts upto 20%. Contact us.

Tc
Special Bulk Discounts

for colleges, Schools, Companies and resellers

Tc
Cash on Delivery

Available above Rs 999

Tc
Highlights
  • Original, High Quality
  • KitsGuru Warranty
Services
  • Email Support
  • Video Support to be purchased separately
Easy Payment Options
  • Netbanking
  • Debit/Credit cards
  • Cash on Delivery
  • E-wallets/UPI
Shipping Details
International Shipping
Available

  Need Volume Discounts? Deals are specially designed for you. Click here

  Need Customization? Provide us more details Click here

  • Order within
Secure

Specification

Description

Ebike MY1016Z3 24V 350W Gear DC Motor comes with gear reduction which produces more low-end torque than your standard motor. This Gear DC Motor is great for those who want to make their own custom electric vehicle, whether it’s a scooter, electric bicycle, or something the world isn’t even ready for. You can change motor direction to left or right by just reversing wires. You can also use the following recommended products with this motor. If you are wandering to build an E-bike and don’t know what will be the best Motor for you then worry no more, we have got your back. At KitsGuru, we have everything for you to get started with your E-bike project.

This 350W Gear DC Motor is a popular reduction dc motor & it’s simply the most commonly used motor for scooters, bikes, and quads available in the market! Also due to its robustness, it is also in many DIY projects like Segway, e-cars, etc, and in many robots like ATV robots, combat robots, etc. We understand the inventive mind and the thrill of creating something all your own. That is why we are proud to present the Ebike MY1016Z3 24V 350W Gear DC Motor – 324 RPM complete with a 9 teeth sprocket having 1/2″ (12.7mm) pitch.
  • This Gear Reduction Motor Complete With A 9 Tooth 1/8" Bicycle Chain Sprocket.
  • It is the most popular reduction dc motor
  • This motor is capable of rotation in either the clockwise or counterclockwise direction by reversing the motor’s power wires.
  • The motor has a gearbox attached to it.

Technical Details

  • Operating Voltage (VDC) : 24
  • Model : MY1016Z3
  • Operating Power : 350 watt
  • Rated Current(A) : 19.2
  • Rated Speed After Reduction (RPM) : 324
  • Rated Torque (Kg-Cm) : 110
  • Stall Torque(Kg-Cm) : 110
  • Sprocket : 9 teeth
  • Pitch(inch) : 1/2
  • Weight (Kg) : 2.8
  • Gearbox : Yes
  • Cable Length (Meter) : 0.5

Physical Attributes

  • Length  * Height  (mm) : 140 * 125
  • Weight (kg) : 2.8
