HC-05 6 Pin Bluetooth Module with Button (Master and Slave) with Button
Review: 5 - "A masterpiece of literature" by , written on May 4, 20020
Great

HC-05 6 Pin Bluetooth Module with Button (Master and Slave) with Button

Available:In Stock
  • Product SKU: KG037
Wishlist
₹ 349 ₹ 489
Available offers
Best Rates

on Express Shipping – Hurry! Shipping starts from Rs59.

Tc
Free Shipping Offer -

Avail free shipping on all orders above Rs999.

Tc
Volume Discounts-

Buy More Save More! Discounts upto 20%. Contact us.

Tc
Special Bulk Discounts

for colleges, Schools, Companies and resellers

Tc
Cash on Delivery

Available above Rs 999

Tc
Highlights
  • Original, High Quality
  • KitsGuru Warranty
Services
  • Email Support
  • Video Support to be purchased separately
Easy Payment Options
  • Netbanking
  • Debit/Credit cards
  • Cash on Delivery
  • E-wallets/UPI
Shipping Details
International Shipping
Available
Options
Details
  • TTL HC05 O/P Bluetooth Module (Master + Slave) New and Original
  • TTL HC05 O/P Bluetooth Module (Master + Slave) Compatiable Version

  •   Need Volume Discounts? Deals are specially designed for you. Click here

      Need Customization? Provide us more details Click here

    Warehouse Details   11F-142 18E-133

    • Order within
    Secure

    Specification

    Description

    HC-05 6 Pin Wireless Serial Bluetooth Module is a Bluetooth module for use with any microcontroller. It uses the UART protocol to make it easy to send and receive data wirelessly. It is small in size, has low power consumption, high sensitivity for sending and receiving. The module is mainly used for short-range data wireless transmission, such as Bluetooth wireless data transmission, Industrial remote control, telemetry, Traffic, underground positioning, alarm, smart home, etc.

    The HC-06 module is a slave-only device. This means that it can connect to most phones and computers with Bluetooth but it cannot connect to another slave-only device such as keyboards and other HC-06 modules. To connect with other slave devices a master module would be necessary such as the HC-05 version which can do both master and slave.

    Features

    • Working current: matching for 30 mA, matching the communication for 8 mA.
    • Dormancy current: no dormancy.
    • Used for a GPS navigation system, water, and electricity gas meter reading system.
    • With the computer and Bluetooth adapter, PDA, seamless connection equipment.
    • Bluetooth module HC-08 Master and slave Two in one module.
    • Use the CSR mainstream Bluetooth chip, Bluetooth V2.0 protocol standards.
    • Potter default rate of 9600, the user can be set up.
    • Bluetooth protocol: Bluetooth Specification v2.0+EDR
    • Speed: Asynchronous: 2.1Mbps(Max) / 160 kbps, Synchronous: 1Mbps/1Mbps.
    • Profiles: Bluetooth serial port.
    • Security: Authentication and encryption.

    Specifications

    • Model: HC-05 (Master+Slave)
    • Input Supply voltage (V) : 3.6 ~ 6
    • Input current (mA) : 50
    • Maximum Operating Range (m) : 10
    • Operating Frequency : 2.4GHz ISM band
    • Modulation: GFSK (Gaussian Frequency Shift Keying)
    • Emission power : 4dBm, Class 2
    • Sensitivity: -84dBm at 0.1% BER
    • Operating Temperature (℃) : -20 ~ +75

    Applications

    • Embedded Projects.
    • Industrial Applications.
    • Computer and Portable Devices.
    • GPS receiver.

    Physical Attributes

    • L * W * H in mm : 37 * 16.5 * 7
    • Weight in gm: 3

    Integration with Arduino

    Sample Code


    Integration with Raspberry Pi


    Sample Code


    Product Video

    Documentation

    Package Includes

    • 1 x HC-05 6 Pin Bluetooth Module with Button (Master and Slave) with Button

    Customer Reviews

    Based on 26 reviews
    88%
    (23)
    8%
    (2)
    4%
    (1)
    0%
    (0)
    0%
    (0)
    s
    sanjeev
    Good and five star

    best product.. working absolutely fine

    p
    parth madan
    excellent

    verry good with very nice packageing

    p
    pawan
    Best for beginners

    thought it was a defective product but now I know I was not giving enough supply to it and then it workedIt is good for beginners

    M
    Mr Nischay

    HC-05 6 Pin Bluetooth Module with Button (Master and Slave) with Button

    m
    meadors
    The best working

    Good product but packaging make different so it's safe

    B
    Bourlet François-Xavier
    Awesome

    Working fantasticBut I think price is little bit high

    t
    tammanne
    Best one

    Best for engineering projects, home projects also easy to install accurate product.

    P
    Praveen
    Tested and working well, Good Product...

    Tested and working well, Good Product...

    h
    hina
    Awesome product

    Working properly.Good bluetooth range.It is a HC 05 bluetooth module.

    s
    satnosh
    Good working product

    Very good
