L293D Motor Driver Board for ESP8266 WiFi NodeMcu Lua ESP12E

Available:In Stock
  • Product SKU: LGGE269
Wishlist
₹ 127 ₹ 159
Available offers
Best Rates

on Express Shipping – Hurry! Shipping starts from Rs69.

Tc
Free Shipping Offer -

Avail free shipping on all orders above Rs999.

Tc
Volume Discounts-

Buy More Save More! Discounts upto 20%. Contact us

Special Bulk Discounts

for colleges, Schools, Companies & resellers Contact us

Cash on Delivery

Available above Rs 499

Tc
Highlights
  • Original, High Quality
  • KitsGuru Warranty
  • Dual H-Bridge: Control 2 DC motors or 1 stepper motor.
  • Voltage Range: 4.5V to 36V.
  • Output Current: Up to 600mA per channel.
  • PWM Control: Enables speed regulation.
  • Easy Integration: Compatible with ESP8266 NodeMCU.
Services
  • Email Support
  • Video Support to be purchased separately
Easy Payment Options
  • Netbanking
  • Debit/Credit cards
  • Cash on Delivery
  • E-wallets/UPI
Shipping Details
International Shipping
Available

  Need Volume Discounts? Deals are specially designed for you. Click here

  Need Customization? Provide us more details Click here

Warehouse Details   26F-143

Secure

Specification

Description

The L293D motor driver board is a commonly used motor driver module that is compatible with various microcontrollers, including the ESP8266 WiFi NodeMcu Lua ESP12E development board. It is used to control DC motors or stepper motors in various projects.

In this motor shield board, the IO port of the ESP-12E Dev Kit is used as the control port. The logic chip configured inside can finish IC driven. Thus, the shield board has four ports: D1, D2, D3, and D3, which are used as PWMA(motor A), PWMB (motor B), DA (direction of motor A), and DB (direction of motor B), respectively. In addition, this shield board has many pins, such as VIN, 3.3V, DIO, AIO, SDIO, UART, SPI, RST, and EN, thus can conveniently connect all kinds of sensors (e.g., temperature and humidity, buzzer, light, relay sensor, etc.)

Details about the L293D motor driver board and its use with the ESP8266 NodeMcu:

Motor Driver IC: The L293D motor driver board is built around the L293D IC, which is designed to control two DC motors in either forward or reverse direction. It can also control a single stepper motor.

Voltage Compatibility: The L293D motor driver board typically operates at a logic voltage level of 5V, which is compatible with many microcontrollers like the ESP8266 NodeMcu. The board can also handle higher motor supply voltages, which vary depending on the specific L293D IC used.

Motor Channels: This module provides two motor channels, often labeled as "Motor A" and "Motor B." Each channel can control one DC motor. For stepper motor control, both channels can be used in tandem.

Direction Control: You can control the direction of each DC motor by toggling the input pins for each channel. By changing the logic levels on these pins, you can make the motors rotate forward or backward.

PWM Control: If you want to control the speed of DC motors, you can use Pulse Width Modulation (PWM) signals from the ESP8266 NodeMcu to control the enable pins on the motor driver board. This allows you to vary the motor speed by adjusting the duty cycle of the PWM signal.

Input Pins: You will typically need to connect four GPIO pins from the ESP8266 NodeMcu to control the direction and speed of the two motors. Each motor has an input pin for direction and another for speed control.

Power Supply Pins: The motor driver board will require a separate power supply for the motors, typically in the range of 4.5V to 36V, depending on the specific L293D IC used. It's essential to provide the appropriate voltage for your motors.

Applications:

The L293D motor driver board is commonly used in robotics, automation, and DIY projects where DC motor control is needed. It's a versatile choice for controlling motors with microcontrollers like the ESP8266 NodeMcu.

Technical Details

  • Motor power supply Range : 4.5V ~ 36V
  • Control power Range : 4.5V ~ 9V (10VMAX)
  • Logic Operating current : ≤60mA
  • Drive part of the work current Io : ≤1.2A
  • Maximum power dissipation : 4W
  • Drive Type: Dual high-power H-bridge driver
  • Working temperature : -25 ℃ ~ + 125 ℃

Features

  • ESP12 DEV KIT development board expansion module
  • Lead ESP12 DEV KIT all the features of pins: SPI, UART, GPIO, AI, and 3.3V power connector
  • Extend two-way motor-driven, two-way direct-drive motor
  • onboard power switch
  • Motor power, control power separation

Physical Attributes

  • L x W x H (mm): 60 x 45 x 13
  • Weight (gm) : 20

Documentation

Product Video

Package Includes

  • 1 x L293D Motor Driver Board for ESP8266 WiFi NodeMcu Lua ESP12E
