LM321MX/MFX (A63A) Low Power Op-Amp IC – SOT-23-5 SMD Package

The LM321MX/MFX (A63A) is a versatile, single-channel, low-power operational amplifier (op-amp) designed for compact, cost-sensitive applications. Housed in a space-saving SOT-23-5 surface-mount package, it provides rail-to-rail output swing, stable operation across a wide supply range, and is ideal for portable and battery-powered devices.

The LM321 offers low supply current, high gain-bandwidth, and wide input common-mode voltage, making it a suitable choice for signal conditioning, filtering, and buffering in analog and mixed-signal circuits.

Technical Details

  • IC Name: LM321MX/MFX (Marking: A63A)
  • Type: Single-Channel Low Power Operational Amplifier
  • Package: SOT-23-5 (Surface Mount)
  • Supply Voltage Range: 3V to 32V (Single Supply)
  • Supply Current: ~430µA (typical)
  • Gain Bandwidth Product: ~1 MHz
  • Output Voltage Swing: Rail-to-Rail (typical)
  • Input Offset Voltage: ±3mV (typical)
  • Input Common-Mode Voltage Range: Includes ground
  • CMRR: ~65dB (typical)
  • Operating Temperature Range: –40°C to +125°C

Features

  • Single low-power op-amp in compact SOT-23-5 package
  • Rail-to-rail output voltage swing
  • Low supply current (~430µA)
  • Wide supply voltage range up to 32V
  • Unity-gain stable
  • Input includes ground (ideal for single-supply operation)
  • High gain and bandwidth for general-purpose use

Applications

  • Signal conditioning and buffering
  • Battery-powered instruments
  • Portable medical devices
  • Sensor interface circuits
  • Active filters and analog front-ends
  • Low-power analog circuits and IoT systems

Physical Attributes

  • Package: SOT-23-5
  • Pin Count: 5
  • Dimensions: ~3.0mm x 1.75mm x 1.1mm (L x W x H)
  • Mounting Type: Surface Mount (SMT)
  • Weight: ~0.05g

Package Includes

  • 1 x LM321MX/MFX (A63A) Low Power Op-Amp IC – SOT-23-5 Package
