0-100V (99.9V) DC Digital Voltmeter Panel .56 inch Red LED Bike Car
- Product SKU: KG231
Need Volume Discounts? Deals are specially designed for you. Click here
Need Customization? Provide us more details Click here
Warehouse Details
- Order within
Specification
Description
Introducing our 0.56-inch Three Wire DC Voltmeter in a striking blue hue, designed to provide accurate voltage measurements in the range of 0 to 100 volts. This compact and reliable voltmeter is equipped with three wires for seamless installation and efficient monitoring of your electrical systems.With its clear 0.56-inch display, this voltmeter ensures easy readability, allowing you to quickly assess voltage levels with precision. The vibrant blue color not only adds a touch of style but also enhances visibility, making it an attractive and functional addition to your instrumentation.
Whether you're working on DIY electronics projects, monitoring batteries, or overseeing industrial applications, our Three Wire DC Voltmeter is a versatile tool that delivers consistent and dependable results. Its user-friendly design and durable construction make it suitable for various environments, providing you with the confidence to tackle voltage measurements with ease.
How to use Components:
Display: The 0.56-inch display typically shows the measured voltage.Input Wires: Usually, there are three wires - red (positive), black (negative), and white (signal).
Power Connection: Connect the red wire to the positive terminal of the power source. Connect the black wire to the negative terminal of the power source.
Signal Connection (if applicable): If there is a white wire, it is likely a signal wire. Connect it to the part of the circuit where you want to measure the voltage.
Power On: Once the connections are made, power on the circuit.
Read the Display: The voltage measurement should now be visible on the 0.56-inch display.
Interpretation: Read the displayed voltage value. Most likely, it will display the voltage in volts (V).
Tips:
Voltage Range: Ensure that the voltage being measured is within the specified range of the voltmeter (0-100V in this case).
Polarity: Pay attention to the polarity. Connecting the red wire to the negative terminal and vice versa can damage the voltmeter.
Accuracy: These meters usually have a certain level of accuracy. Keep in mind the precision required for your measurements.
Calibration (if needed): Some voltmeters may need calibration. Refer to the product documentation for any calibration procedures.
Technical Details
- Wide measurement range 0-99.9V.
- Mini Red LED display.
- Low power consumption.
- Refresh speed: 500ms.
- Snap-on design for easy installation.
- led colors: Red.
- Refresh speed: about 500ms/each time.
- Power supply: DC 4.5v - 28V. Working temperature: -10? - 65 ?.
Physical Attributes
- Length × Width x Height (mm): 48 * 29 * 21
- Weight (gm) : 17
- Color: Black
Package Includes
- 1 x 0-100V (99.9V) DC Digital Voltmeter Panel .56 inch Red LED Bike Car
