Original BTA16-800C TRIAC – 800V 16A TO-220 for AC Switching

The BTA16-800C is a high-performance TRIAC designed for AC switching applications. With a voltage rating of 800V and a current rating of 16A, it is suitable for use in dimmers, motor controls, and AC load switching. Its TO-220 insulated package offers excellent thermal performance and ease of mounting for power circuits.

Technical Details

  • Part Number: BTA16-800C
  • Type: TRIAC (Bidirectional Triode Thyristor)
  • Repetitive Peak Off-State Voltage (VDRM): 800V
  • RMS On-State Current (IT(RMS)): 16A
  • Gate Trigger Voltage (VGT): ~1.3V
  • Gate Trigger Current (IGT): ~35mA
  • Holding Current (IH): ~35mA
  • Surge Current (ITSM): 160A
  • Package: TO-220 (Insulated)
  • Mounting Type: Through-Hole

Features

  • High voltage capability up to 800V
  • Rugged and reliable design for AC applications
  • Insulated TO-220 package for safety
  • High surge current capability
  • Suitable for general-purpose AC power control

Applications

  • AC Motor Speed Control
  • Light Dimmers
  • Heater Control
  • Static AC Switches
  • Solid-State Relays

Physical Attributes

  • Package: TO-220 (Insulated)
  • Leads: 3 (MT1, MT2, Gate)
  • Dimensions: Approx. 10mm × 15mm × 4.5mm
  • Mounting Type: Through-Hole
  • Weight: ~1.2g

Package Includes

  • 1 x Original BTA16-800C TRIAC – 800V 16A TO-220
