Magnetic Reed Switch module Reed Sensor
Reed Switch Module
Reed Switch Module

Reed Switch Module

Available:In Stock
  • Product SKU: KG180
Wishlist
₹ 59 ₹ 99
Available offers
Best Rates

on Express Shipping – Hurry! Shipping starts from Rs69.

Tc
Free Shipping Offer -

Avail free shipping on all orders above Rs999.

Tc
Volume Discounts-

Buy More Save More! Discounts upto 20%. Contact us

Special Bulk Discounts

for colleges, Schools, Companies & resellers Contact us

Cash on Delivery

Available above Rs 999

Tc
Highlights
  • Original, High Quality
  • KitsGuru Warranty
Services
  • Email Support
  • Video Support to be purchased separately
Easy Payment Options
  • Netbanking
  • Debit/Credit cards
  • Cash on Delivery
  • E-wallets/UPI
Shipping Details
International Shipping
Available

  Need Volume Discounts? Deals are specially designed for you. Click here

  Need Customization? Provide us more details Click here

Warehouse Details   12F-144

  • Order within
Secure

Specification

Description

This Reed Switch Module can be applied in Program-controlled switches, copiers, washing machines, refrigerators, cameras, Disinfection cabinets, door, window magnetic, electromagnetic relays, electronic weighing, level meter, gas meter, water meter, and so on.


Reed Switch Module Kit is a kind of passive electronic switching component with contacts with a simple structure, small size, and easy to control. It consists of a sealed glass envelope where there are two ferrous elastic reeds and is filled with an inert gas called rhodium.


The reed switch must work together with the magnet, when it detects magnetism, the circuit is connected and the module outputs a low level; when there is no magnetic force, it is disconnected and the module outputs a high level. If the sensing range of the reed to the magnet is more than 1.5cm, it will become insensitive and it may not be triggered

Technical Details

  • Operating Voltage (VDC) : 3.3 ~ 5
  • Max. Operating Current (mA) : 1200
  • Output format: Digital switching output ( 0 and 1 )

Physical Attributes

  • Length × Width (mm) : 32 × 14
  • Weight (gm) : 3

Integration with Arduino


Sample Code


Additional Details

  • Clean, good waveform driving ability, more than 15mA.
  • Working voltage 3.3V-5
  • Output format: digital switching output (0 and 1)
  • A  fixed bolt holes for easy installation
  • PCB size: 3.2cm x 1.4cm
  • Digital output using a wide voltage LM393 comparator
