Digital Rotary Encoder Module Rotary Potentiometer With Knob Cap
Review: 5 - "A masterpiece of literature" by John Doe, written onMay 4, 20020
Great
-37%
Digital Rotary Encoder Module Rotary Potentiometer  With Knob Cap
Digital Rotary Encoder Module Rotary Potentiometer  With Knob Cap _1
Digital Rotary Encoder Module Rotary Potentiometer  With Knob Cap _3

Digital Rotary Encoder Module Rotary Potentiometer With Knob Cap

Available:Out of Stock
  • Product SKU: KG1006
Wishlist
₹ 149 ₹ 239
Successful pre-order.Thanks for contacting us!
Secure

Specification

Description

The rotary encoder can count the number of output pulses during forward and reverse rotation by rotating. Unlike the potentiometer, the rotation counting is not limited. With the buttons on the rotary encoder, it can be reset to the initial state, that is, counting from 0.

Working principle:

An incremental encoder is a rotary sensor that converts rotational displacement into a series of digital pulse signals. These pulses are used to control angular displacement. The conversion of angular displacement in the Eltra encoder uses the photoelectric scanning principle. The reading system is based on the rotation of a radial indexing disk (code disk) composed of alternating light-transmitting windows and opaque windows and is vertically illuminated by an infrared light source, which projects the image of the code disk onto the receiver surface. The receiver is covered with a diffraction grating with the same window width as the code disk.

Common Applications:

Digital Rotary Encoder Module

  • User input controls in electronic devices (e.g., volume control on a stereo).
  • Position feedback in industrial machinery and robotics.
  • Navigation and scrolling in user interfaces (e.g., rotary encoders on computer mice).
  • Angular position measurement in scientific instruments.

Rotary Potentiometer

  • Volume and tone controls in audio equipment.
  • Setting parameters in electronic circuits (e.g., adjusting the gain in an amplifier).
  • Control knobs in industrial panels and instrumentation.
  • User interface elements in consumer electronics.

Technical Details

  • Model: PIR HC-SR501
  • Operating Voltage (VDC): 4.5 ~ 20
  • Average Current Consumption (mA): 0.06
  • Distance Measuring Range (CM): 300 ~ 700
  • Output Type : (High/ Low-level Signal) 3.3V TTL output
  • Working Temperature Range (°C): -20 to 80
  • Detection Angle: <140°
  • Delay Time: 5 to 200s (Can be Adjusted, Default 5s +/- 3%)

Features

  • Steps width of 20 positions/revolution
  • It has a switch included in the Encoder
  • Rotates a full 360 degrees
  • Operating voltage range of 5V

Pinout of the Module

Applications

  • Robotic arm controller
  • Servo and Stepper motor control
  • Precise motor movement

Physical Attributes

  • Weight (gm): 18

Product Video

Documentation

Package Includes

  • 1 x Digital Rotary Encoder Module Rotary Potentiometer With Knob Cap
