STM32F103C8T6 Minimum System Development Board (ARM Cortex-M3)

The STM32F103C8T6 Minimum System Development Board is a low-cost ARM Cortex-M3 based microcontroller board designed for learning, development, and prototyping with STM32 microcontrollers.

Powered by the STM32F103C8T6, this board features a 32-bit ARM Cortex-M3 core running at up to 72 MHz, making it suitable for embedded systems, automation, robotics, and IoT applications.

The board includes essential components such as a crystal oscillator, reset circuitry, and an onboard Micro-USB interface for power supply and USB communication, providing a convenient minimum system for STM32 learning.

Note: Actual product appearance may vary slightly (for example, tact switch style).

Key Features

  • Based on STM32F103C8T6 microcontroller
  • ARM Cortex-M3 32-bit CPU
  • Maximum operating frequency: 72 MHz
  • 64 KB Flash memory
  • 20 KB SRAM
  • Operating voltage: 2.0 – 3.6 V
  • Onboard Micro-USB interface for power and USB communication
  • Reset (POR / PDR) support
  • External crystal support (4 – 16 MHz)
  • Compact minimum system design

Technical Specifications

  • Item Type: Development Board
  • Based On: STM32
  • Model Name: STM32F103C8T6
  • Core Architecture: ARM Cortex-M3 (32-bit)
  • Clock Speed: Up to 72 MHz
  • Flash Memory: 64 KB
  • SRAM: 20 KB
  • Operating Voltage: 2.0 – 3.6 V
  • Debug Interface: SWD

Physical Attributes

  • Board Dimensions: 54 × 23 mm
  • Weight: 10g

Applications

  • STM32 learning and training
  • ARM Cortex-M3 development
  • Embedded systems and automation
  • Robotics and control projects
  • IoT and industrial applications

Package Includes

  • 1 × STM32F103C8T6 Minimum System Development Board
  • 1 × Male Header
