XB8358D Voltage Regulator IC – 5V Low Dropout Regulator (SOT-23-5)
The XB8358D is a high-precision, low dropout (LDO) linear voltage regulator that provides a fixed 5V output with up to 500mA of current. Designed for space-constrained and battery-powered applications, it is housed in a compact SOT-23-5 surface-mount package.The regulator offers excellent line/load regulation, low dropout voltage, and low quiescent current. Integrated thermal shutdown and short-circuit protection ensure robust operation under fault conditions.
Note: For best performance, use 1µF ceramic capacitors on both input and output pins.
Technical Details
- IC Name: XB8358D
- Type: Fixed 5V Low Dropout Voltage Regulator
- Output Voltage: 5V ±2%
- Output Current: Up to 500mA
- Input Voltage Range: 5.5V to 12V
- Dropout Voltage: ~300mV @ 100mA, ~600mV @ 500mA
- Quiescent Current: ~45µA typical
- Line Regulation: ±0.2% typical
- Load Regulation: ±0.4% typical
- PSRR: ~70dB @ 1kHz
- Thermal Shutdown Protection
- Short Circuit and Overcurrent Protection
- Package: SOT-23-5
- Mounting Type: Surface Mount (SMT)
- Operating Temperature: -40°C to +85°C
Features
- Fixed 5V regulated output
- Delivers up to 500mA output current
- Low dropout and low quiescent current
- Excellent line and load regulation
- High PSRR for noise-sensitive applications
- Built-in thermal shutdown and short-circuit protection
- Compact SOT-23-5 surface-mount package
Applications
- 5V logic level power supplies
- Microcontroller and sensor modules
- Battery-operated and portable devices
- IoT and wireless modules (e.g., LoRa, Wi-Fi, BLE)
- Analog circuits and low-noise designs
Physical Attributes
- Package: SOT-23-5
- Pin Count: 5
- Dimensions: ~2.9mm x 1.6mm x 1.1mm (L x W x H)
- Mounting Type: Surface Mount (SMT)
- Weight: ~0.05g
Package Includes
- 1 x XB8358D 5V LDO Voltage Regulator IC (SOT-23-5 Package)
