12V 150W MY6812 Electric DC Motor with Sprocket
![12V 150W MY6812 E-Bike Gear DC Motor]()
![12V 150W MY6812 E-Bike Gear DC Motor_2]()
![12V 150W MY6812 Electric DC Motor with Sprocket]()
![12V 150W MY6812 E-Bike Gear DC Motor]()
![12V 150W MY6812 E-Bike Gear DC Motor_2]()
![12V 150W MY6812 Electric DC Motor with Sprocket]()
The motor is equipped with a pre-installed 7-tooth sprocket compatible with 25H chains, simplifying installation and ensuring consistent power transfer. With enhanced speed, improved torque, and excellent build quality, the MY6812 150W version is a reliable solution for demanding applications.
-20%
12V 150W MY6812 Electric DC Motor with Sprocket
Available:In Stock
- Product SKU: KGEB010
₹ 1,349
₹ 1,699
Need Volume Discounts? Deals are specially designed for you. Click here
Need Customization? Provide us more details Click here
Warehouse Details
Specification
Description
12V 150W MY6812 E-Bike Gear DC Motor
The MY6812 12V 150W DC Motor is a compact, high-torque brushed motor built for small electric vehicles, robotics, and DIY projects requiring extra power. Delivering a robust 150-watt output, it offers smooth, efficient performance ideal for e-bikes, scooters, and chain-driven mechanisms. Its sturdy construction and precision manufacturing ensure dependable operation under continuous load conditions.The motor is equipped with a pre-installed 7-tooth sprocket compatible with 25H chains, simplifying installation and ensuring consistent power transfer. With enhanced speed, improved torque, and excellent build quality, the MY6812 150W version is a reliable solution for demanding applications.
Technical Details
- Item Type: Brushed Motor
- Model No.: MY6812
- Operating Power (W): 150
- Rated Voltage (V): 12
- No Load Current (A): 1.2
- Rated Current (A): 14.3 approx
- Rated Torque (kg-cm): 48 approx
- Stall Torque (kg-cm): 160 approx
- Stall Current (A): 52 approx
- No-load Shaft Speed: 3450 RPM
- Rated Shaft Speed: 2350 RPM (5–10% lower than no-load RPM)
- Sprocket: 7 tooth, #25 bicycle chain
- Left or Right rotation by Reversing Wires
- Pitch: #25 pitch chain (6.35 mm)
- Weight: 1.3kg
- Cable Length: 50 cm
- Gear:No
Features
- Higher output power (150W) for demanding electric drive systems
- Durable black steel housing for long service life
- Pre-mounted sprocket for quick and easy chain connection
- Low idle current for efficient energy use
- Enhanced torque output and stable operation under load
Applications
- Electric bicycles and scooters
- DIY go-karts and small utility vehicles
- Robotics and automated machinery
- Motorized toys and hobby vehicles
- Portable conveyor systems
Sprocket Details
- Sprocket Type: Fixed on motor shaft
- No. of Teeth: 7T
- Pitch: #25 / 25H (6.35 mm)
- Tooth Thickness: 6.35 mm
- Chain Compatibility: Standard #25 / 25H bicycle & e-bike chains
- Material: High-strength steel
- Durability: Wear-resistant, long life
- Application: E-bike, scooter, mini bike drive system
Drawing
Physical Attribute
- Number of teeth: 7 teeth
- Pitch: 6.35mm
- Shaft end thread: M6-left (anti-thread)
- Tooth thickness: 6.35mm
- Weight: 1.30kg
- Compatible with 25H model chain
- Wiring length: 500mm
- Dimensions (L x D): 120 mm x 68 mm
Package Includes
- 1 x 12V 150W MY6812 Electric DC Motor with Sprocket
