24V 350W MY1016Z2 Electric E-BIKE Brush Motor
Review: 5 - "A masterpiece of literature" by John Doe, written onMay 4, 20020
Great

24V 350W MY1016Z2 Electric E-BIKE Brush Motor

Available:In Stock
  • Product SKU: KGEB058
Wishlist
₹ 3,199 ₹ 3,999
Available offers
Best Rates

on Express Shipping – Hurry! Shipping starts from Rs69.

Tc
Free Shipping Offer -

Avail free shipping on all orders above Rs999.

Tc
Volume Discounts-

Buy More Save More! Discounts upto 20%. Contact us

Special Bulk Discounts

for colleges, Schools, Companies & resellers Contact us

Cash on Delivery

Available above Rs 499

Tc
Highlights
  • Original, High Quality
  • KitsGuru Warranty
  • Model: MY1016-Z
  • Voltage: 24 V
  • Rated Amps: 18.4 A
  • Current Type: DC
  • Power: 350 W
  • Rated Speed: 3000 RPM
Services
  • Email Support
  • Video Support to be purchased separately
Easy Payment Options
  • Netbanking
  • Debit/Credit cards
  • Cash on Delivery
  • E-wallets/UPI
Shipping Details
International Shipping
Available

  Need Volume Discounts? Deals are specially designed for you. Click here

  Need Customization? Provide us more details Click here

Warehouse Details   SR-1

Secure

Specification

Description

24V 350W MY1016Z2 Electric E-BIKE Brush Motor

The MY1016Z2 is a compact and powerful 24V 350W electric brush motor commonly used in e-bikes, scooters, and small electric vehicles. It features a robust build with a durable housing and an integrated gear reduction system. The motor operates at a rated speed of 3000 RPM and is designed for efficient energy conversion, making it ideal for medium-duty applications. Its output power of 350W ensures a good balance of performance and battery efficiency, contributing to longer rides and reliable torque.

This model includes a built-in gearbox with a reduction rate of 9.6:1, enhancing torque output for better hill climbing and load handling. It is designed to operate with a standard 24V DC power supply. Its mounting configuration and wiring are user-friendly, making it easy to install in most DIY electric vehicle projects. Ideal for hobbyists and engineers, this motor delivers reliable and consistent performance in a compact form.

Technical Details

  • Model: 1016-Z
  • Voltage: 24V DC
  • Output Power: 360W
  • Rated Speed: 3000 RPM
  • Rated Amps: 18.4 A
  • Gear Reduction Ratio: 9.6:1 (Marked as 9.6 RLDHYD-RIT)
  • Motor Type: Brushed DC Motor
  • Application: E-bikes, scooters, DIY electric vehicles
  • Mounting Type: Base mount with pre-drilled holes
  • Output Shaft: Sprocket-type for chain drive
  • Reversible Direction: Yes (by swapping polarity)
  • Rated Torque: 110 kg-cm
  • Stall Torque: 350 kg-cm
  • Sprocket: 9 teeth
  • Weight: 2.87 kg
  • Gearbox: Yes
  • Cable Length: 0.5 m

Features

  • High-performance 24V 350W brushed DC motor for electric bikes and scooters
  • Delivers strong torque output with a rated torque of 110 kg-cm and a stall torque of 350 kg-cm
  • Equipped with a durable built-in gearbox (gear ratio 9.6:1) for torque multiplication
  • Rated speed of 324 RPM ensures steady and powerful motion under load
  • Compatible with 9-tooth sprocket for standard chain drives
  • Robust construction with a total weight of 2.87 kg for stability and durability
  • Ideal for heavy-duty e-bike conversions, electric carts, and mobility projects
  • Pre-attached 0.5 m cable for easy installation and connectivity
  • Reliable choice for DIY enthusiasts and commercial electric vehicle applications

Applications

  • Electric bicycles (e-bikes)
  • Electric scooters
  • Go-karts and mini-bikes
  • Electric tricycles and rickshaws
  • DIY electric vehicle projects
  • Portable mobility vehicles
  • Motorized wagons or carts
  • Robotic drive systems
  • Home-built electric wheelchairs
  • Educational and prototyping projects

Package Includes

  • 1 x 24V 350W MY1016Z2 Electric E-BIKE Brush Motor
