74HC30D 8-Input NAND Gate IC – High-Speed CMOS Logic, 16-Pin SMD

The 74HC30D,653 is an 8-input NAND gate from Nexperia, designed to perform NAND logic with eight input lines and one output. This device is part of the HC logic family, which utilizes CMOS technology for low power consumption and high-speed performance.

Technical Details

  • IC Type: Gate IC
  • Gate Type: NAND
  • Model: 653, 74HC30D
  • Package: SMD-14
  • Supply Voltage: 5V
  • Propagation Delay: 12 ns
  • Operating Temperature Range: -40°C to +125°C

Features

  • 8-Input NAND Gate
  • Propagation Delay: 12 ns for fast switching
  • Supply Voltage: 5V
  • Output Current: 5.2 mA (low), -5.2 mA (high)
  • Operating Temperature Range: -40°C to +125°C

Applications

Digital Logic Circuits – Ideal for implementing complex logic operations in embedded and digital systems

Microcontroller and Processor Interfaces – Used to combine multiple input signals into a single logical control output

Signal Monitoring and Control Systems – Perfect for triggering actions based on multiple sensor inputs or logic conditions.

Physical Attributes

  • Dimensions: ~4.6mm x 3.7mm x 1.8 mm (L x W x H)
  • Weight: ~0.05g
