The motor’s robust metal housing provides excellent heat dissipation and durability, making it ideal for continuous or intermittent operation. Capable of generating up to 220V output (open circuit) when used as a generator, it offers outstanding conversion efficiency for small renewable-energy or mechanical-to-electrical conversion experiments.
-16%
High-Efficiency 50W PMDC Motor – 220V Hand-Crank Generator with Double Ball Bearings
Available:In Stock
- Product SKU: LGGE336
₹ 2,499
₹ 2,999
Need Volume Discounts? Deals are specially designed for you. Click here
Need Customization? Provide us more details Click here
🏠
Warehouse Details:
Specification
Description
High-Efficiency 50W PMDC Motor – 220V Hand-Crank Generator with Double Ball Bearings
This High-Efficiency 50W PMDC Motor is designed for use as a hand-crank generator or DC power source in DIY projects, wind-powered systems, and educational applications. Built with precision double ball bearings for smooth operation and extended service life, it ensures stable performance even under variable mechanical loads.The motor’s robust metal housing provides excellent heat dissipation and durability, making it ideal for continuous or intermittent operation. Capable of generating up to 220V output (open circuit) when used as a generator, it offers outstanding conversion efficiency for small renewable-energy or mechanical-to-electrical conversion experiments.
Features
- High-efficiency 50W permanent-magnet DC motor
- Can be used as a motor or a hand-crank generator
- Sturdy all-metal construction with aluminum front plate
- Equipped with double ball bearings for long life
- Low noise and smooth operation
- Ideal for DIY renewable-energy and hand-powered projects
Technical Details
- Rated Power: 50W
- Rated Voltage: 220V (DC output when used as generator)
- Rated Speed: 3000–6000 RPM
- Output Type: 2-wire (Red: +, Blue: −)
- Bearings: Double ball bearings
- Motor Type: Permanent-Magnet DC (PMDC)
- Body Material: Metal housing with vented front plate
- Shaft Diameter: 8mm D-Type
- Mounting Hole Pitch: 44mm (approx.)
- Dimensions: 60mm (Dia) × 90mm (L)
- Weight: 1066g
Applications
- DIY hand-crank generators and wind-powered projects
- Educational experiments and physics demonstrations
- Battery charging (with regulator)
- Renewable-energy prototype systems
- Small mechanical-to-electrical conversion setups
Package Includes
- 1 × 50W 220V PMDC Motor with Double Ball Bearings
