Unwelded GY-SHT30-D Digital Temperature and Humidity Sensor
![temperature and humidity monitor GY-SHT30-D module]()
![sht30 sensor based digital temperature module]()
![temp humidity monitor with I2C interface]()
![temperature and humidity monitor GY-SHT30-D module]()
![sht30 sensor based digital temperature module]()
![temp humidity monitor with I2C interface]()
Moreover, this temperature and humidity monitor features improved signal processing and two selectable I2C addresses, which ensures smooth integration into different platforms. Each sht30 sensor is individually calibrated, with coefficients stored directly on-chip, resulting in consistent performance and long-term reliability.
![W1209 digital temperature controller module front view]()
![W1209 digital thermostat module with NTC thermometer sensor]()
-21%
Unwelded GY-SHT30-D Digital Temperature and Humidity Sensor
Available:In Stock
- Product SKU: KG1272
₹ 234
₹ 299
Need Volume Discounts? Deals are specially designed for you. Click here
Need Customization? Provide us more details Click here
🏠
Warehouse Details:
Specification
Description
Unwelded GY-SHT30-D Temperature and Humidity Monitor
The GY-SHT30-D is a compact and high-precision temperature and humidity monitor designed for reliable environmental sensing. Built around the advanced sht30 sensor, this digital module delivers stable and accurate readings while maintaining low power consumption. As a dependable temp humidity monitor, it supports modern monitoring needs across embedded and IoT systems.Moreover, this temperature and humidity monitor features improved signal processing and two selectable I2C addresses, which ensures smooth integration into different platforms. Each sht30 sensor is individually calibrated, with coefficients stored directly on-chip, resulting in consistent performance and long-term reliability.
Features
- Digital output for temperature and humidity monitoring
- High accuracy with temperature ±0.3°C and humidity ±3%
- Low power consumption and compact design for embedded use
- I2C communication interface with two selectable addresses
- On-chip calibration coefficients for precise measurements
- Humidity sensor resolution: 12–8 bit
- Temperature sensor resolution: 14–12 bit
- Temperature range: -40 to +125°C
- Humidity range: 0–100% with 1% resolution
Technical Details
- Item Type: Sensor
- Model Type: Temperature and Humidity Sensor
- Rated Voltage: 2.4 to 5.5V
- Model Name: GY-SHT30-D
- Response Time: > 2s
- Dimensions (L×W): 12 × 10 mm
- Weight: 5 g
Package Includes
- 1 × Unwelded GY-SHT30-D Digital Temperature and Humidity Sensor
