Pro-Range XKC-Y26-V-DC 5-24V Non-Contact Liquid Level Sensor
![Pro-Range XKC-Y26-V-DC 5-24V Non-Contact Liquid Level Sensor]()
![Pro-Range XKC-Y26-V-DC 5-24V Non-Contact Liquid Level Sensor]()
![Pro-Range XKC-Y26-V-DC 5-24V Non-Contact Liquid Level Sensor]()
![Pro-Range XKC-Y26-V-DC 5-24V Non-Contact Liquid Level Sensor]()
![Pro-Range XKC-Y26-V-DC 5-24V Non-Contact Liquid Level Sensor]()
![Pro-Range XKC-Y26-V-DC 5-24V Non-Contact Liquid Level Sensor]()
The sensor probe is mounted externally on the upper or lower side of non-metallic containers or pipelines, allowing quick installation without drilling or opening the container. It is ideal for detecting liquid levels of toxic substances, strong acids, strong alkalis, and other liquids stored in high-pressure or airtight environments. The XKC-Y26 series is specially developed for non-metallic pipeline liquid level detection and offers wide compatibility with various container materials.
![Turbidity Sensor with Module]()
![Turbidity Sensor with Module_1]()
-19%
Pro-Range XKC-Y26-V-DC 5-24V Non-Contact Liquid Level Sensor
Available:Out of Stock
- Product SKU: KG1316
₹ 524
₹ 649
Specification
Description
Pro-Range XKC-Y26-V DC 5–24V Non-Contact Liquid Level Sensor
The Pro-Range XKC-Y26-V Non-Contact Liquid Level Sensor is an intelligent solution designed for accurate liquid level detection without direct contact. Utilizing advanced signal processing technology and a high-speed processing chip, this sensor overcomes the influence of container wall thickness to achieve true non-contact liquid level detection in closed and sealed containers.The sensor probe is mounted externally on the upper or lower side of non-metallic containers or pipelines, allowing quick installation without drilling or opening the container. It is ideal for detecting liquid levels of toxic substances, strong acids, strong alkalis, and other liquids stored in high-pressure or airtight environments. The XKC-Y26 series is specially developed for non-metallic pipeline liquid level detection and offers wide compatibility with various container materials.
Features
- True non-contact liquid level detection through container walls
- Prevents wear, corrosion, and contamination
- High detection accuracy with ±1.5 mm tolerance
- IP67-rated waterproof and dustproof enclosure
- Compatible with non-metallic containers (plastic, glass, ceramic)
- Suitable for pipelines and sealed containers
- Adjustable sensitivity for optimized detection
- Simple external installation without affecting production
Technical Details
- Item Type: Liquid Level Sensor
- Model No.: XKC-Y26-V
- Operating Voltage: DC 5–24 V
- Detection Method: Non-contact (through container wall)
- Detection Accuracy: ±1.5 mm
- Waterproof Rating: IP67
- Container Requirement: Non-metallic materials
Applications
- Industrial liquid level monitoring
- Chemical processing and storage systems
- Non-metallic pipelines and tanks
- Medical and laboratory equipment
- Food and beverage processing
- Automation and control systems
Physical Attributes
- Compact industrial-grade sensor housing
- Weight: 22g
- IP67 waterproof enclosure
Package Includes
- 1 × Pro-Range XKC-Y26-V DC 5–24V Non-Contact Liquid Level Sensor
- 1 × Small Screw driver
