(2Pcs) SW-18020P Electronic Shaking Switch Vibration Sensor
Review: 5 - "A masterpiece of literature" by John Doe, written onMay 4, 20020
Great

(2Pcs) SW-18020P Electronic Shaking Switch Vibration Sensor

Available:In Stock
  • Product SKU: KG587
Wishlist
₹ 22 ₹ 199
Available offers
Best Rates

on Express Shipping – Hurry! Shipping starts from Rs69.

Tc
Free Shipping Offer -

Avail free shipping on all orders above Rs999.

Tc
Volume Discounts-

Buy More Save More! Discounts upto 20%. Contact us

Special Bulk Discounts

for colleges, Schools, Companies & resellers Contact us

Cash on Delivery

Available above Rs 499

Tc
Highlights
  • Original, High Quality
  • KitsGuru Warranty
Services
  • Email Support
  • Video Support to be purchased separately
Easy Payment Options
  • Netbanking
  • Debit/Credit cards
  • Cash on Delivery
  • E-wallets/UPI
Shipping Details
International Shipping
Available

  Need Volume Discounts? Deals are specially designed for you. Click here

  Need Customization? Provide us more details Click here

Warehouse Details   16E-125

Secure

Specification

Description

SW-18020P Vibration Sensor is a really simple vibration switch, it is used commonly in electronics toys, alarms, domestic appliances, electronics devices, smart home systems. SW-18020 series is spring type, Non-direction vibration induced trigger switches, any angle can be a trigger

Technical Details

  • Max Voltage : 12V
  • Max Current: 50mA
  • Conductive Time: ~2ms
  • Closed Resistance: < 10 ohm
  • Open Resistance: > 10M ohm
  • Operating Temperature Range: -40 to 80 C
  • Pull Force of Terminal: 500gf for 1 min
  • Operating Lifespan:up to 200,000 cycles

Features

  • SW-18020 series is spring type, Non-direction vibration induced trigger switches, any angle can be trigger.
  • The series of switches, at the rest is open circuit “OFF-state”, When the external force to touch and reach the corresponding vibration, Or move in speed to reach the adequate centrifugal force. The conductive feet will be conduct instantaneously “ON-State”. When the external force disappear, the switches will be revert the “OFF-State”.
  • In the normal, the switches lifespan can be reached 200,000 cycles.
  • Suitable for the toys, anti-theft alarm system, electronics scales etc electronic product.
  • It doesn’t have a direction, normally it’s open circuit inside, and it turns to close when it is shaked  instantly, and then turn to open again when motion is gone.

Physical Attributes

  • H x W (mm): 22 x 4
  • Weight (gm) : 1

Documentation

Package Includes

  • 2 x SW-18020P Electronic Shaking Switch Vibration Sensor
