MAX3232 RS232 Serial Port to TTL Serial Interface Module DB9

This RS232 to TTL Serial Interface Module is a board with the MAX3232 transceiver integrated circuit (IC). It facilitates serial communication between TTL and RS232 ports by providing the necessary electrical signal conversion.

These boards usually have a DB9 connector soldered at one end, and four header pins for jumper cables at the other end. The jumper cables enable the user to connect the wires to a breadboard or a microcontroller project board, whilst the DB9 connects directly to a COM port of a computer.

The MAX3232 IC, which comes in a 16 pin narrow SO package. It requires between 3.0 V to 5.5 V to operate and has two receivers and two transmitters. It has a maximum guaranteed data rate of 120 kbps, and the circuitry requires four 0.1µF charge-pump support capacitors. It is also compatible with the famous MAX3232 IC pins. These boards connect to systems with a UART hence, they work with ATMEL and PIC microcontrollers.

MAX3232 RS232 Serial Port To TTL Converter Module DB9 Connector 5V RS232 to TTL + Female Serial TTL + serial modules / Brush board. This module can be used to the serial port of the microcontroller module expand DVD, router, hard drive, and other equipment to upgrade.

Note : SP3232zEEN Printed on IC working remains same.

Technical Details

  • Model Type: Interface Module
  • Length × Width × Height(mm) : 35 × 32 × 15
  • Weight (gm) : 11

Features

  • Used in radio mods, phone flash, XBOX360 flash, GPS, vehicle detection, DVD flash, hard disk repair, and set-top box upgrades.
  • Programs STC, NXP, Renesas, STM32, and N+-2EC MCUs.
  • Pre-assembled compact board.
  • Works with most microcontrollers.
  • Operates up to 250 kbit/s.

Applications :

  • Microcontroller Communication: Facilitates communication between microcontrollers and devices using RS232 interfaces.
  • PC-to-MCU Interface: Converts RS232 signals to TTL levels for seamless connection between computers and microcontroller-based systems.
  • Embedded Systems Debugging: Used for debugging and monitoring embedded systems via serial communication.
  • Industrial Automation: Enables connectivity with legacy RS232-based industrial equipment.
  • POS Systems: Connects peripherals like barcode scanners or printers to Point-of-Sale systems.
  • Data Logging Systems: Transfers data between sensors or instruments and PCs for logging and analysis.
  • Serial Device Connectivity: Allows interfacing with modems, GPS modules, and other RS232-enabled devices.

Physical Attributes

  • Length × Width × Height(mm) : 35 × 32 × 15
  • Weight (gm) : 11

Package Includes

  • 1 x MAX3232 RS232 Serial Port to TTL Serial Interface Module DB9
