TDA8932 Digital Power Amplifier Board 35W Mono High-Power TDA8932 Low Power Consumption
Review: 5 - "A masterpiece of literature" by John Doe, written onMay 4, 20020
Great

TDA8932 Digital Power Amplifier Board 35W Mono High-Power TDA8932 Low Power Consumption

Available:Out of Stock
  • Product SKU: KG611
Wishlist
₹ 339 ₹ 466
Successful pre-order.Thanks for contacting us!
Secure

Specification

Description

The TDA8932 is a digital power amplifier integrated circuit (IC) that is commonly used in audio amplifier applications. When integrated into a circuit board, it can be used to create a mono-channel audio amplifier with a power output of around 35 watts.

Key Features:

Digital Amplification: The TDA8932 is a Class D amplifier, which means it operates in a digital switching mode. This design results in high efficiency and low power consumption.

Mono Configuration: The TDA8932 is typically used to create a mono-channel amplifier, which is suitable for single-channel audio applications, such as subwoofers or center-channel speakers in a home theater system.

High Power Output: It can deliver up to approximately 35 watts of power into an 8-ohm speaker load when powered by a suitable power supply.

Low Power Consumption: One of the advantages of Class D amplifiers like the TDA8932 is their low power consumption, especially when compared to traditional linear amplifiers (Class A or Class AB).

Integrated Protection Features: Many TDA8932-based amplifier boards include built-in protection features such as overcurrent protection and thermal shutdown, which help prevent damage to the amplifier and connected speakers.

Compact Design: The amplifier board typically has a compact form factor, making it suitable for integration into a variety of audio equipment and speaker systems.

Ease of Use: These amplifier boards are often designed to be easy to use, with labeled input and output connectors and mounting holes for easy installation.

Common Uses:

DIY Audio Projects: Enthusiasts and hobbyists often use TDA8932-based amplifier boards in DIY audio projects to create amplifiers for various purposes, including subwoofers and powered speakers.

Home Audio Systems: They can be used to enhance the audio capabilities of home audio systems, particularly for driving subwoofers or dedicated audio channels.

Audio Equipment Upgrades: Some users may choose to upgrade the amplifier section of their audio equipment, such as amplifiers integrated into home theater receivers.

Portable Audio Devices: Due to their efficiency and low power consumption, TDA8932-based amplifiers are suitable for battery-powered audio devices like portable speakers and headphone amplifiers.

Education and Prototyping: Educational institutions and engineers may use these amplifier boards for prototyping and teaching purposes.
TDA8932 Digital Power Amplifier Board 35W Mono High-Power TDA8932 Low Power Consumption

Technical Details

  • Module Type: TDA8932 35W
  • Operating Voltage: Single DC10 ~ 30V
  • Recommended Voltage: 24V
  • Current: Above 2A Switching Power Supply
  • Output Power: 35W x 1
  • Speaker Impedance: 4-8 ohm, 8 ohm best
  • Circuit configuration: Mono BTL Output

Features

  • The board uses a high-performance digital amplifier TDA8932 chip.
  • Produce good quality sound with this module.
  • Mono digital audio power amplifier chip.
  • High output and low power consumption.
  • Suitable for the transformation of active speakers, product development, and other audio applications.

Application

  • Public address system
  • Sound reinforcement system
  • In domestic uses such as home- theatre system
  • Instrument amplifiers including guitar amplifiers or keyboard amplifier

Physical Attributes

  • L x W x H (mm): 45 x 31 x 10
  • Weight (gm): 10

Documentation

Package Includes

  • 1 x TDA8932 Digital Power Amplifier Board 35W Mono High-Power TDA8932 Low Power Consumption
