This V-output variant provides a high and low level signal output for connection to compatible controllers. The sensor has a specified maximum detection distance of up to 10m, a factory-default setting of approximately 5m and a response time of less than 1500ms. Actual sensing performance depends on installation position, the target and surrounding conditions.
Its microwave signal can pass through suitable non-metallic materials, including glass, plastic, ceramic, acrylic, rubber and wood, allowing installation behind compatible covers. An ABS+PC housing with IP67 protection and a specified operating temperature of -10°C to 60°C support use in indoor and appropriately installed outdoor environments.
-14%
XKC-LD500B 5.8GHz Microwave Human Presence Detection Sensor – V Output
Available:In Stock
- Product SKU: KG1450
₹ 899
₹ 1,048
Need Volume Discounts? Deals are specially designed for you. Click here
Need Customization? Provide us more details Click here
🏠
Warehouse Details:
Specification
Description
XKC-LD500B 5.8GHz Microwave Human Presence Detection Sensor – V Output
The XKC-LD500B Microwave Human Presence Sensor uses 5.8GHz microwave radar to detect human movement and small body movements, such as those associated with breathing or typing. Its non-contact sensing design is suitable for occupancy-based lighting, smart appliances, building automation and compatible electronic control systems.This V-output variant provides a high and low level signal output for connection to compatible controllers. The sensor has a specified maximum detection distance of up to 10m, a factory-default setting of approximately 5m and a response time of less than 1500ms. Actual sensing performance depends on installation position, the target and surrounding conditions.
Its microwave signal can pass through suitable non-metallic materials, including glass, plastic, ceramic, acrylic, rubber and wood, allowing installation behind compatible covers. An ABS+PC housing with IP67 protection and a specified operating temperature of -10°C to 60°C support use in indoor and appropriately installed outdoor environments.
Features
- 5.8GHz microwave radar for human presence and movement detection
- Detects larger movements and subtle body micro-movements
- V-model high and low level signal output
- Specified maximum sensing distance of up to 10m
- Factory-default sensing distance of approximately 5m
- Response time of less than 1500ms
- Integrated microwave sensing, signal processing and microcontroller functions
- Designed to resist interference from dust, smoke and ambient temperature changes
- Can detect through suitable non-metallic covers and panels
- Compact threaded sensor with panel-mount housing
- ABS+PC enclosure with IP67 dust and water ingress protection
- Suitable for presence-controlled lighting and automation
Technical Details
- Item Type: Microwave Human Presence Detection Sensor
- Model No.: XKC-LD500B-V
- Sensing Technology: Microwave Radar
- Operating Frequency: 5.8GHz
- Output Type: V (High and Low Level Signal)
- Maximum Specified Sensing Distance: Up to 10m
- Factory-Default Sensing Distance: Approximately 5m
- Response Time: <1500ms
- Detectable Movement: Human movement and subtle body micro-movements
- Operating Temperature: -10°C to 60°C
- Housing Material: ABS+PC
- Waterproof Rating: IP67
- Standard Cable Length Shown in Drawing: 500mm
- Wire Connections Shown: Brown – VCC; Yellow – OUT; Blue – GND; Black – NC (not connected)
Applications
- Occupancy-based lighting in offices, corridors and restrooms
- Human presence monitoring in rooms and workspaces
- Smart-home and building-automation controllers
- Automatic lighting in warehouses and parking areas
- Presence-activated digital signage and advertising displays
- Automatic control of compatible fans and appliances
- Security systems and presence-triggered alerts
- Detection behind suitable non-metallic enclosures
Drawing
Wiring Diagram
Wire Connections
- Brown: Positive power supply (VCC)
- Blue: Negative power supply (GND)
- Yellow: High/low signal output (OUT) to a compatible controller input
- Black: NC (no connection, as labelled in the supplied V-output wiring drawing)
- Use a controller input and regulated power supply compatible with the exact V-model's electrical ratings.
Physical Attributes
- Housing Type: Cylindrical Threaded Panel-Mount Housing
- Housing Material: ABS+PC
- Thread Size Shown: M28 (pitch not specified)
- Front Face Diameter: Ø30mm
- Overall Front Housing Width Shown: 33mm
- Sensor Body Length Shown: 21.45mm
- Standard Cable Length Shown: 500mm
- Mounting Type: Threaded Panel Mount with Retaining Nut
- Waterproof Rating: IP67
Installation and Usage Notes
- Mount the sensor facing the intended occupancy area, allowing for the required detection distance.
- Compatible non-metallic covers may be used, but detection through them varies with material and thickness.
- Avoid placing metal obstructions directly in front of the sensing face.
- Verify detection of both movement and small body motions under actual installation conditions.
- Confirm the exact operating supply voltage and signal output levels for the supplied V variant before wiring.
Package Includes
- 1 × XKC-LD500B 5.8GHz Microwave Human Presence Detection Sensor – V Output with Cable
